Product Series: CA Series (3U)
Product Name: CA12 / CA18 / CA20/ CA28
Features:
The CA series offers 2U-3U height options and a power range of 200W-1750W with 20 precision meters on the front panel to show the transients and spikes of each channel signal.
TourClass protectors are included and include ACL, IGM, AutoRamp and other tour protection instructions.
The dynamic peak amplitude limiting feature of the ACL prevents the square wave impact from entering the loudspeaker and is virtually full band protection; the AutoRamp automatically attenuates the power amplifier each time the amplifier is turned on or restarted.
| Model |
CA12 |
CA18 |
CA20 |
CA28 |
| Output Power 8Ω |
900W |
1200W |
1250W |
1500W |
| Output Power 4Ω |
1400W |
1850W |
2000W |
2600W |
| Bridge Power 8Ω |
2600W |
3800W |
3800W |
3200W |
| Frequency response |
20Hz~20KHz ±0.5dB |
| THD |
＜0.03% 8Ω 1khz |
| S/N Ratio |
93dB |
| Transient response |
44V/μS |
| Damping factor |
﹥300 |
| Crosstalk |
>70dB 1KHz |
| Input impedance |
20KΩ（Balanced)/10KΩ（Unbalanced) |
| Input sensitivity |
0.775/1.0/1.4 V |
| Output circuitry |
Class H |
| Protection |
Over heat, Short circuit, DC safeguard, Over Loading, Boot-Strap Short Test |
| Dimensions |
650×585×220 |
